Automatic Water Faucet Dispenser Sensor SLC-00002
Model No.: SLC-00002
Power Supply: DC 4.3～6.4V
Static Power: ≤30uA
Working Mode: Automatic on/off
Optional Working Mode: Wave on/off
Default Sensor Distance: 5cm
Adjustable Sensor Range: 2cm-12cm
Max Output Current: 800mA
Output Pulse Width: 35ms
Low Voltage Indicator: Yes
Application: Water fountain/dispenser
Certificate: CE, RoHS
Automatic Water Dispenser and Faucet Sensor SLC-00002
$6.00
Description
As the most important part, the work of the sensor is to forward the signals to the valve to turn on the faucets/ water filling stations/ water dispensers/ water fountains after detecting your hand or water bottle. Its job is to inform the valve when to start or stop the flow based on the presence or absence of your hand/ water bottle or water cup. The sensor SLC-00002 is perfect for residential and commercial automatic faucets, water filling stations, touchless water dispensers and no-touch water fountains.
Infrared Sensor Applications
The infrared sensor is widely used in public washrooms, such as touchless faucets, automatic urinal flusher, automatic toilet flusher and automatic soap dispenser. The infrared sensors can be also used for touchless kitchen faucets and bathroom faucets.
Working Principle
Active infrared touchless sensors use the emission and reception of infrared beams to detect the presence and/or movement of objects or people in their field of detection. The technology is ideal for applications requiring a long and narrow detection range.
The sensor eye SLC-00002 is widely used for residential and commercial automatic faucets, water filling stations, touchless water dispensers and no-touch water fountains.
How the automatic water tap and water dispenser works?
Automatic on/off. You put your hands/ water bottle/water cup on the sensor range, water automatically flows. You remove your hands/ water bottle/water cup out of the sensor range, water automatically stops. The water will automatically stop flowing if continuously flowing for 30 seconds (We call this function security stop timing and this timing can be customized).
Besides sensor, Rajeyn is capable of providing the whole electronic sets for automatic water dispensers, including drinking water solenoid valve, battery pack or AC transformer. Now we have AC24V solutions for water filling stations/ water dispensers.
Rajeyn Sensor Features and Applications
- Used for commercial and household touchless faucets/water dispensers etc.
- Adjustable sensor range and flushing time by a remote controller.
- Auto-save parameters if power failure.
- Low power consumption. 4AA alkaline batteries lasts about 2 years.
- Glue potting with strong moisture-proof function.
- High anti-interference and anti-vibration performance.
- We have more than 50 different sensor eyes and electrical wires for your selection.
- The automatic valve closing function of AC power-off can be widely used in intelligent bathroom products.
There are over 50 different sensor housings to suit different design PCBAs. They are variety of designs for all-in-one type and separated PCBA. Shapes including round, rectangle, semicircular etc. The sensor functions and wire connections can be tailor-made based on cc
Besides sensor cases, we have variety of waterproof wire connections. The most popular types are 4-pin waterproof wire connecting with control box for sensor taps and 2-pin as well as DC type waterproof wires for sensor urinal and sensor toilets. Below are some potting sensors with different sensor cases, PCBA and wires. We are capable of providing tailor-made infrared sensors for your automatic systems.
